MGT8012UB-R25 Series G Protechnic 12V 0.66A fan

Description

The Protechnic MGT8012UB-R25 is a powerful 12V DC axial fan measuring 80x80x25mm, designed for high-performance cooling in various electronic systems. Featuring a ball bearing system, it ensures robust durability and a long operational lifespan of 50,000 hours. This fan delivers a substantial 68.88 CFM of airflow and a strong static pressure of 0.361 In H2O at 4800 RPM, making it highly effective for dissipating heat from components in servers, inverters, power supplies, and other demanding industrial or computing equipment. With a noise level of 45.2 dBA, the MGT8012UB-R25 offers a strong balance of intense cooling capacity and reliable operation.

Manufacturer: Protechnic Electric
Model: MGT8012UB-R25 Series G
Type: DC Axial Fan
Dimensions: 80mm x 80mm x 25mm
Nominal Voltage: 12V DC
Operating Voltage Range: 4.0V to 13.8V DC
Current: 0.82A
Power Consumption: 9.84W
Speed: 4800 RPM
Airflow: 68.88 CFM
Static Pressure: 0.361 In H2O
Noise Level: 45.2 dBA
Bearing Type: Ball Bearing
Termination: 3-wire leads
Life Expectancy: 50,000 hours at 70°C
Frame and Blade Material: PBT
Features: Auto-Restart, Locked Rotor Protection, Reverse Connection Protection, Motor Protection
Safety Approvals: UL, TUV, CE
MGT8012UB-R25 Series G new Yongli MAGIC 8025 12V 0.66A high-volume cooling fan
MGT8012UB-R25 Series G Protechnic MAGIC 12V 0.66A fan
