TG12038HA2BL Jiulong 220V AC Axial Fan

Description

The Jiulong TG12038HA2BL is a 220VAC Axial Fan with dimensions of 120x120x38mm, designed for effective cooling in various applications. This fan operates on 220VAC, drawing 0.14A of current and consuming 22W of power. It achieves a speed of 2600RPM, delivering 180.094m³/h (106CFM) of airflow with a noise level of 46dB(A). This fan provides reliable air movement for general cooling and ventilation systems.

TG12038HA2BL Fan Parameters
Model: TG12038HA2BL
Manufacturer: Jiulong
Type: AC Axial Fan
Dimensions: 120 x 120 x 38 mm
Nominal Voltage: 220 V AC
Frequency: 50/60 Hz
Rated Current: 0.14 A
Power Consumption: 22 W
Speed: 2600 RPM
Airflow: 180.094 m³/h (106 CFM)
Noise Level: 46 dB(A)
Weight: 600 g
Application: General cooling and ventilation systems.
