Description
The ebmpapst S6E330-AP02-30 is a high-performance 230VAC Φ 410 x 128 mm AC axial fan, engineered for reliable thermal management in commercial refrigeration, evaporators, and HVAC systems. Driven by the M6E068-DF motor, this industrial cooling fan features maintenance-free ball bearings, a robust phosphated steel guard grille coated in black plastic, and a 5-blade sheet steel impeller painted black. It delivers an airflow of 824.0 / 965.0 CFM (1400.0 / 1640.0 m³/h / 23.33 / 27.33 m³/min) and a static pressure of 6.12 / 7.14 mmH₂O (60.0 / 70.0 Pa / 0.24 / 0.28 inH₂O) at a rated speed of 940 / 1,100 RPM. Operating on a nominal voltage of 230 VAC (50/60 Hz), it draws a maximum current of 0.33 / 0.32 A with a starting current of 0.55 / 0.5 A and a power consumption of 65 / 72 W. Equipped with internal thermal overload protection (TOP), an integrated motor capacitor (2 µF / 400 VDB / 450 VDB), and axial cable connections, it offers IP44 protection, insulation class B, H0+ environmental protection, touch current < 0.75 mA, and condensation drainage holes on the rotor side. Built for continuous S1 operation, it weighs 3.90 kg, operates within an ambient temperature range of -25 to +50 / +65 °C (storage -40 to +80 °C), offers a life expectancy of 40,000 hours, and holds safety certifications including CE and RoHS.
S6E330-AP02-30 Fan Parameters
Manufacturer: ebmpapst
Model Number: S6E330-AP02-30
Motor: M6E068-DF
Type: AC Axial Fan
Nominal Voltage: 230 VAC
Operating Voltage Range: 200 – 240 VAC (50/60 Hz)
Dimensions: Φ 410 x 128 mm
Impeller Size: 330 mm
Number of Blades: 5
Weight: 3.90 kg
Guard Grille Material: Steel (Phosphated and coated with black plastic)
Impeller Material: Sheet Steel (Painted black)
Rotor Surface: Painted black
Bearing Type: Ball Bearing
Power Connection Type: Axial Cable
Rated Speed: 940 / 1,100 RPM (min⁻¹)
Max. Current Draw: 0.33 / 0.32 A
Starting Current: 0.55 / 0.5 A
Max. Power Consumption: 65 / 72 W
Motor Capacitor: 2 µF / 400 VDB (50Hz), 450 VDB (60Hz)
Capacitor Standard: S0 (CE)
Touch Current: < 0.75 mA
Motor Protection: Thermal overload protector (TOP) internally connected
Degree of Protection: IP44 (installation- and position-dependent as per EN 60034-5)
Insulation Class: “B”
Moisture / Environmental Protection Class: H0+
Condensation Drainage Holes: On rotor side
Operation Mode: S1
Max. Air Flow: 824.0 / 965.0 CFM (1400.0 / 1640.0 m³/h / 23.33 / 27.33 m³/min)
Max. Static Pressure: 6.12 / 7.14 mmH₂O (60.0 / 70.0 Pa / 0.24 / 0.28 inH₂O)
Noise Level: 58 dBA
Operating Temperature: -25 – +50 / +65 °C
Storage Temperature: -40 – +80 °C
Life Expectancy: 40,000 hours
Safety Approvals: CE, RoHS
Application
The ebmpapst S6E330-AP02-30 is deployed in commercial refrigeration evaporators, walk-in coolers, condensing units, heat exchangers, industrial air conditioning systems, and general HVAC ventilation equipment.
